Recently I was helping someone get bootstrapped on their Axum project, and they were getting a bit frustrated with the lack of context about the goings on in their application. While Axum and it's ecosystem are well instrumented, by default most of it is not very well surfaced for beginners. It can be a bit intimidating figuring out how to put the pieces together and use them.
Once we set up tracing
and color_eyre
our logging and errors went from looking like this:
Listening on [::]:8080
Got an error request on `/error`
Got request for `/favicon.ico`, but no route was found.
Got a homepage request on `/`
To something with a little bit more context:
INFO Listening on [::]:8080
INFO request:get_error: Got an error request uri=/error method=GET source=::1
ERROR request:
0: Whoopsies
ââââââââââââââââââââââââââââââââââ SPANTRACE âââââââââââââââââââââââââââââââââââ
0: demo::routes::get_error
at src/routes.rs:11
1: demo::trace_layer::request with uri=/error method=GET source=::1
at src/trace_layer.rs:24
Backtrace omitted. Run with RUST_BACKTRACE=1 environment variable to display it.
Run with RUST_BACKTRACE=full to include source snippets. uri=/error method=GET source=::1
INFO request:get_home: Got a homepage request uri=/ method=GET source=::1
INFO request:fallback_404: Got request, but no route was found. uri=/favicon.ico method=GET source=::1
While this isn't a complete and fully mature solution suitable for an industrial application, it is a good starting point for them that smoothly evolve into something more mature.
Often the first place I start with a binary project is the command line interface, so we'll start there.
Making instrumentation tuneable
Instrumentation can have many knobs, this project used clap
, so we took the existing Cli
struct and added an instrumentation
field:
// src/cli/mod.rs
use Parser;
use ;
pub
Using #[clap(flatten)]
here means we can define all our instrumentation options in a separate struct, while still appearing in the --help
as one might expect:
âŊ cargo run -- --help
Finished dev [unoptimized + debuginfo] target(s) in 0.04s
Running `target/debug/demo --help`
Usage: demo [OPTIONS]
Options:
--bind <BIND>
[env: DEMO_BIND=]
[default: [::]:8080]
-v, --verbose...
Enable debug logs, -vv for trace
[env: DEMO_VERBOSITY=]
--logger <LOGGER>
Which logger to use
[env: DEMO_LOGGER=]
[default: compact]
[possible values: compact, full, pretty, json]
--log-directive [<LOG_DIRECTIVES>...]
Tracing directives
See https://docs.rs/tracing-subscriber/latest/tracing_subscriber/filter/struct.EnvFilter.html#directives
[env: DEMO_LOG_DIRECTIVES=]
-h, --help
Print help (see a summary with '-h')
Tracing offers use the choice of several built in logging styles, or even our own logging style if we so choose!
It's quite easy to pass on this choice to the user, though we do need to create Logger
enum to represent that choice:
// src/cli/logger.rs
pub
The Logger
can then get used in in our Instrumentation
struct, which we'll build up over the next few code blocks:
// src/cli/instrumentation.rs
use WrapErr;
use ;
use Subscriber;
use ;
use Logger;
pub
This interface offers users the ability to specify 'traditional' verbosity options such as -v
or, my favorite, -vvvvvvv
through the use of clap::ArgAction::Count
.
It also permits the use of more tracing
-specific options like the Logger
we created above, or the option of any number of tracing_subscriber::filter::Directive
. We'll explore those a bit together once we get things running.
We can then attach some functions to this struct that set up a Registry
which stores span data, such as the data defined in #[tracing::instrument]
calls.
In a setup()
function we'll build a Registry
and compose it with several layers, including a ErrorLayer
and an EnvFilter
layer we configure from the knobs made available in the Cli
struct (as well as some conventional environment variables):
Then we can go ahead and define the various format layers, along with any customization we wanted to do.
Later, your project may choose to integrate something like tracing_opentelemetry
and route that data to a service like Honeycomb.
Building up Error
s
axum
allows us to define routes that can return errors, if that error implements axum::response::IntoResponse
:
async
Unfortunately, this does not work out of the box with eyre::Report
.
It's also forbidden for us (as demo
) to implement IntoResponse
for Report
due to the Orphan Rule, so we must create a wrapper. While we do that, we might as well create a crate-specific DemoError
as well, which can be later used to define user-facing error messages and status codes.
// src/error.rs
use ;
pub type Result<T, E = Report> = Result;
// A generic error report
// Produced via `Err(some_err).wrap_err("Some context")`
// or `Err(color_eyre::eyre::Report::new(SomeError))`
;
// Tell axum how to convert `Report` into a response.
pub
// Tell axum how to convert `DemoError` into a response.
Now we can use that new Result
in our routes, and return errors either ad-hoc via eyre::eyre
, or structured through the error type we created with thiserror
.
This is also a good opportunity to decorate your routes with a
tracing::instrument
attribute.Consider using
skip_all
and explicitly defining any fields if you are dealing complex route arguments! Eg.#[tracing::instrument(skip_all, fields(uid = context.user.uid))]
.
use crate Result;
use IntoResponse;
use eyre;
pub async
At the start, and during prototyping, you can use eyre::eyre
to write easy ad-hoc errors.
As the application grows, you'll be able to work with thiserror
and use downcast_ref
(like we did in the instrumentation.rs
code) and other tools available in eyre::Report
to respond with a more structured and informative messages to the web browser.
use crate Result;
use IntoResponse;
// After adding a `Spooky` variant to `DemoError` in `src/error.rs`:
//
// #[derive(thiserror::Error, Debug)]
// enum DemoError {
// #[error("A spooky thing happened")]
// Spooky
// }
pub async
Putting the pieces together
After painting our user interface and performing the ritualistic type dancing, it's finally time to update main()
with the code to get everything working.
At the very top of main()
we want to install color_eyre
's error hooks, so that any errors after that are fully styled and integrated.
After that, we can call setup()
on the Instrumentation
instance created by clap
to initialize tracing.
In order to add the appropriate spans to requests, tower_http::trace::TraceLayer
should be added to the axum::routing::Router
:
// src/main.rs
use crate::;
use get;
use Parser;
use ;
use TraceLayer;
async
TraceLayer
offers opportunities to attach our own functions where we can create spans or emit events.
There exist defaults (tower_http::trace::{DefaultMakeSpan, DefaultOnRequest}
) which can be modified using a builder API, these have the rather unfortunate quality of being part of the tower_http
crate, not our own, so because the defaults we configured in the Instrumentation::filter_layer()
function they won't normally be enabled.
Defining our own functions allows us to build our own base span, as well as ensure these spans are part of our own crate.
If your project opts to use the defaults, consider altering Instrumentation::filter_layer()
to also set some default for tower_http
.
// src/trace_layer.rs
use ;
use ;
use ;
use Span;
pub
pub
pub
We can create a few test routes a fallback route, one reporting no error, another reporting an eyre::eyre
based error, and a route reporting a DemoError
.
Due to our error handling code we can use DemoError
variants to return specific, user-facing messages and status codes, while more ad-hoc or developer/operator facing errors can be eyre::eyre
based.
// src/routes.rs
use crate;
use IntoResponse;
use eyre;
pub async
pub async
pub async
pub async
If you're following along you may have run cargo add
for some of the dependencies above, the specific examples shown utilized the following features and crates:
# Cargo.toml
[]
= "demo"
= "0.1.0"
= "2021"
[]
= "0.6"
= { = "4.3", = ["derive", "env"] }
= { = "0.6", = false, = [ "issue-url", "tracing-error", "capture-spantrace", "color-spantrace" ] }
= "0.14"
= "1"
= { = "1", = ["full"] }
= "0.4"
= { = "0.4", = ["trace"] }
= "0.1"
= "0.2"
= { = "0.3", = ["env-filter", "json"] }
One feature you may wish to enable the track-caller
on color-eyre
package, it will show the locations of errors in the output using the track_caller
attribute.
The reported location is not always accurate, but often it's helpful.
Going for a test run
At this point, we can run our binary and visit the homepage:
)
We can run the application again with different directives and get some more info from one of the packages, for example hyper
which does the bulk of the HTTP work:
)
)
)) )
# ...
That's a lot of output! We can also use log directives to drill down into specific parts of the code, this can be quite useful for debugging. Here we isolate hyper
events to parse_headers
:
)
)
Or how about only logging requests for a specific URL? We can specify a filter like demo[request{uri=/}]=trace
and visit several pages, observing we only see logs for the one we filtered for:
)
)
Of the different logger options, my personal favorite is the pretty
logger which creates a cozy, human readable experience:
)
The tracing spans also appear in our errors, let's take a look at those. We can observe these errors when we visit the respective /error
urls:
)
Visiting /error/demo
we can observe the browser returning A spooky occured
as we intended.
Conclusion
The combination of thiserror
, tracing
, and color_eyre
provides a solid starting point for a budding project. The ability to instrument code with spans, see those spans in errors, then filter based on those spans in logging messages enables greater insight while diagnosing issues and authoring new features. As your project grows, these same tools offer a smooth path to adoption of standards like OpenTelemetry.
While researching this article I bumped into the really lovely article by @carlosmv about a many of the same ideas! They go in detail about how to use tracing_appender
and some other things which are not covered here, but don't discuss error handling as much. If you want to dig deeper into this topic, that article is a wonderful place to visit after this!
A few years ago I gave a recorded talk at TremorCon which discussed tracing
and color_eyre
, and this article expands on several of the concepts mentioned there.
This article was suggested by my employer and friend, @grahamc at Determinate Systems.
